The LiitoKala 8S 24V 100A BMS is a high-performance Battery Management System designed for LiFePO4 battery packs, ensuring optimal safety and longevity. Engineered with balance charging, overcharge and over-discharge protection, temperature safeguards, and short-circuit prevention, this BMS is an ideal solution for e-scooters, e-bikes, and other high-power battery applications.

Key Features

• 100A Discharge & 50A Charge Capacity: Supports high-current applications.
• Balance Charging: Ensures uniform cell voltage for prolonged battery life.
• Overcharge & Over-Discharge Protection: Prevents battery damage by regulating voltage.
• Short-Circuit Protection: Rapid response to external short circuits.
• Temperature Protection: Automatically regulates charging and discharging at 75°C.
• Low Power Consumption: Minimal drain during operation and standby.

Technical Specifications

• Discharge Current: 100A
• Charge Current: ≤50A
• Overcurrent Protection: 600A ±10A
• Main Circuit Resistance: ≤5MΩ
• Product Dimensions: 145 × 65 × 11 ±1mm
• Overcharge Voltage Protection: 3.65 ± 0.025V
• Over-Discharge Voltage Protection: 2.35 ± 0.1V
• Equalization Current: 70 ± 5mA
• Short Circuit Response Time: ≤350µs
• Temperature Protection: Charge & discharge cutoff at 75°C
• Operating Temperature: -20°C to +80°C
